System temperature detector

Constant temperature heat detector manual

Product introduction

This heat detector provides consistent temperature detection and is suitable for any home or commercial applications. The detector consists of an externally mounted thermistor with a specially designed cover that protects the thermistor while allowing maximum airflow. The thermistor reads the temperature from the air it enters and sends a signal representing the temperature to the control IC. If the temperature reaches or exceeds the trip point, the detector is triggered. The status LED lights up red and emits an alarm signal. The detector is an ideal unit for detecting rapid fire developments in homes, shops, hotels, restaurants, offices, schools, banks, libraries, etc.

Product feature

Strong ability to adapt to circumstances

SMT adopted, high stability

Low standby current

9-35VDC wide voltage

The power supply input is non-polarized

The power indicator LED is flashing

Alarm relay N.C./N.O. optional (4 wires)

Remote LED indicator output (2 wires)

Technical Specifications

Product category

2 wire 4 wire

Operating voltage

DC 9V~35V

Standby current

50uA 50uA

Current alarm

20-25 mA at 12V

40-50 mA at 24V

30-35 mA

Alarm signal

Turn on the red LED

The temperature range of

-10°C ~ +50°C, humidity less than 95%RH

Temperature. Trip point

57°C (135°F)

Detection range

50 square meters with an installation height of 6-12 metres

The result of the alarm

Remote LED relay output

Communication evaluation

N/A 0.5A at 28V DC

standard

EN54-5, UL521, GB4716-2005

The dimension

Diameter 98.5mm*43

Depth .5 mm
It is considered one of the most important fire alarm products.
